True 4K HDMI Booster (4K@10m)

Product Code : VB800

Brand Category : Video Extenders

Description

Superior video quality – True 4k resolutions of 4096 x 2160 @ 60 Hz (4:4:4) video and standard 1080p (1920 x 1080 @ 60 Hz)
HDMI (3D, Deep Color, 4K)
Max. Data Rate 18 Gbps (6 Gbps Per Lane)
HDMI and HDCP 2.2 compatible
Supports up to True 4K resolutions when cascaded up to 10 levels

- Up to 10 m True 4K transmission distance (max. 5 m on the input side and 5 m on the output side)
- Up to 20 m 1080p transmission distance (max. 10 m on the input side and 10 m on the output side)

A single unit can be powered from the source device
Supports HDR10+
Plug-and-play – No software installation required
Rack mountable

* Longer distance transmission is allowed with lower data rates and/or higher quality cable

Technical Specification

Video Input
Interfaces	1 x HDMI Type A Female (Black)
Max. Distance	5M at 4096x2160@60Hz (4:4:4)
Video Output
Interfaces	1 x HDMI Type A Female (Black)
Max. Distance	5M at 4096x2160@60Hz (4:4:4)
Video
Max. Bandwidth	600 MHz
Max. Resolutions / Distance	Up to 10M at 4K@60 Hz (4:4:4); Up to 20M at 1080p@60Hz
Max. Data Rate	18Gpbs(6 Gbps Per Lane)
Compliance	HDMI, HDCP 2.2 Compatible
Connectors
Power	1 x DC Jack
Power Consumption	DC5V:0.99W:5BTU
Environmental
Operating Temperature	0 - 40°C
Storage Temperature	-20 - 60°C
Humidity	0 - 80% RH, Non-Condensing
Physical Properties
Housing	Metal
Weight	0.09 kg ( 0.21 lb )
Dimensions (L x W x H)	4.90 x 5.60 x 1.70 cm (1.93 x 2.2 x 0.67 in.)
Carton Lot	10 pcs
