True 4K DisplayPort Booster

True 4K DisplayPort Booster

Product Code : VB905

Brand Category : Video Extenders

Description

  • Extends True 4K signal transmission up to 5 m
  • Compliant with DisplayPort 1.2a and HDCP 2.2
  • Superior video quality – up to True 4K resolutions of 4096 x 2160 @ 60 Hz (4:4:4)
  • Supports HDR
  • Cascade 3 levels to extend True 4K signal up to 20 m
  • A single unit can be powered from the source device
  • Plug-and-play
  • Rack mountable

    Note: Longer transmission distance is possible with lower data rates. If you want to remain high quality transmission, please use higher quality cable.

Add to Query Cart PDF Download

Technical Specification

Video Input
Interfaces1 x DisplayPort Female (20-pin)
Max. DistanceUp to 4Kx2K@60Hz (4:4:4) / 5m
1080p@60Hz / 5m
Video Output
Interfaces1 x DisplayPort Female (20-pin)
Max. DistanceUp to 4Kx2K@60Hz (4:4:4) / 5m
1080p@60Hz / 5m
Video
Max. Data Rate21.6 Gpbs (5.4 Gbps Per Lane)
ComplianceDP1.2a
HDCP 2.2
Max. Resolution4096 x 2160@60Hz (4:4:4)
Connectors
Power1 x DC Jack
Power ConsumptionDC5V:0.937W:4BTU
Environmental
Operating Temperature0 - 40°C
Storage Temperature-20 - 60°C
Humidity0 - 80% RH, Non-Condensing
Physical Properties
HousingMetal
Weight0.05 kg ( 0.11 lb )
Dimensions (L x W x H)5.84 x 3.53 x 2.06 cm
(2.3 x 1.39 x 0.81 in.)
Carton Lot10 pcs
