Single Port KVM over IP Switch with Single Port Power Switch

"

• Hardware
• Provides over-IP capability to servers or KVM switches that do not have built-in over-IP functionality*
• Built in single port Power Switch
• Supports PS/2, USB, Sun Legacy (13W3)** and serial (RS-232) connectivity
• Local console provides PS/2 and USB keyboard and mouse support
• Supports multiplatform server environments: Windows, Mac, Sun, Linux and VT100 based serial devices
• Virtual Media Support
• High video resolution – up to 1920 x 1200 @ 60 Hz with 24 bit color depth for the local console; up to 1920 x 1200 @ 60 Hz with 24 bit color depth for remote sessions
  Note: * Compatible KVM Switches include the following: CS9134, CS9138, CS1308, CS1316, CS1754, CS1758, CS1708A, CS1716A, ACS1208A, ACS1216A, KH2508A, KH2516A, KH1508A and KH1516A (Some of the KN1000A’s features may not be supported, depending on the functionality of the connected KVM switch. For example, some switches do not support virtual media). Some features found on the connected KVM switches may not be supported on the KN1000A. (For example, the CS1754’s audio.)
  ** Requires CV130A converter purchase

• Management
• Up to 64 user accounts
• Up to 32 concurrent logins
• End session feature – administrators can terminate running sessions
• Event logging and Windows-based Log Server support
• Critical system event notification via SMTP email; SNMP trap and Syslog support
• Remote firmware upgradable
• Serial console management – serial terminal access. Access the device connected to KN1000A via a built-in serial viewer, or via third party software (such as PuTTY) for Telnet and SSH sessions
• PPP mode (modem) dial-in/dial out support for out-of-band, and low bandwidth operation
• Port Share Mode allows multiple users to gain access to a server simultaneously
• Integration with ATEN CC2000 Centralized Management Software
• Integration with ATEN PDU for remote power control
• Remote power on and off control function with Wake on LAN
• On/Off scheduling for power outlet. Power management tasks can be scheduled on a daily, weekly, monthly or user specified time basis
• Safe shutdown support
• Auto-Ping pings a device to determine its status, if the ping test fails after a set amount of time – it automatically takes an action assigned
• DDNS (Dynamic Domain Name System)
• Export/import user account and configuration settings
• Manage browser access methods (disable browser, http, or https)

• Easy-to-Use Interface
• Browser-based and AP GUIs offer a unified multilanguage interface to minimize user training time and increase productivity
• Multiplatform client support (Windows, Mac OS X, Linux, Sun)
• Multi-browser support: Internet Explorer, Chrome, Firefox, Safari, Opera, Mozilla, Netscape
• Browser-based UI in pure Web technology allows administrators to perform administrative tasks without pre-installed Java software package required
• Full-screen or sizable and scalable Virtual Remote Desktop window
• Magic Panel – a special hideaway control panel with configurable function icon

• Advanced Security
• Smart Card / CAC Reader Support
• External authentication support: RADIUS, LDAP, LDAPS, and MS Active Directory
• Supports TLS 1.2 data encryption and RSA 2048-bit certificates to secure users log in from browser
• Flexible encryption design allows users to choose any combination of DES, 3DES, AES, RC4, or Random for independent KB/Mouse, video, and virtual media data encryption
• IP/MAC Filter for enhanced security protection
• Supports password protection
• Private Certificate Authority

• Virtual Media
• Virtual media enables file applications, OS patching, software installation and diagnostic testing
• Works with USB enabled servers at the operating system and BIOS levels
• Supports USB 2.0 DVD/CD drives, USB mass storage devices, PC hard drives and ISO images

• Virtual Remote Desktop
• BIOS-level access
• Video quality and video tolerance can be adjusted to optimize data transfer speeds; monochrome color depth setting, threshold and noise settings for compression of the data bandwidth in low bandwidth situations
• Full screen video display or scalable video display
• Message Board for communication among remote users
• On-screen keyboard with multilanguage support
• Mouse Dynasync™
• Exit Macros support

"
