"HDMI HDBaseT Extender with Dual Outputs (4K@100m) (HDBaseT Class A)"

Product Code : VE814

Brand Category : Video Extenders

Description

Extends the distance between HDMI source and HDMI display
Implements HDBaseT extension technology using only one Cat 5 cable to connect the transmitter and receiver
Anti-jamming – resists signal interference during high-quality video transmissions using HDBaseT technology
Supports one local and two remote displays
Supports two IR channels for bi-directional IR signal transmission
Extends Ethernet communication with pass-through port
HDMI (3D, Deep Color,4kx2k); HDCP Compatible
Long distance transmission – up to 100 m
Supports wide screen
Supports resolutions of up to Ultra HD 4kx2k and 1080p Full HD
Supports up to 340 MHz bandwidth for high performance video
EDID Expert – selects the optimum EDID settings for smooth power-up and highest quality display
RS-232 Serial Port for serial device peripherals, such as touch screens, bar coders scanners, and so on
Built-in 8KV / 15KV ESD protection (Contact voltage 8KV; Air voltage 15 KV)
Easy to install – no software required
Rack Mountable

Technical Specification

Function	VE814R	VE814T
Video Input
Interfaces	N/A	1 x HDMI Type A Female (Black)
Impedance	N/A	100 Ω
Max. Distance	N/A	1.8 m
Video Output
Interfaces	2 x HDMI Type A Female (Black)	1 x HDMI Type A Female (Black)
Impedance	100 Ω	100 Ω
Video
Max. Data Rate	10.2 Gbps (3.4 Gbps Per Lane)	10.2 Gbps (3.4 Gbps Per Lane)
Max. Pixel Clock	Up to 340 MHz	Up to 340 MHz
Compliance	HDMI (3D, Deep Color, 4K) HDCP Compatible Consumer Electronics Control (CEC)	HDMI (3D, Deep Color, 4K) HDCP Compatible Consumer Electronics Control (CEC)
Max. Resolutions / Distance	Up to 4K@70m (Cat 5e/6) / 100m (cat 6a); 1080p@100m *4K supported: 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)	Up to 4K@70m (Cat 5e/6) / 100m (cat 6a); 1080p@100m *4K supported: 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
Audio
Input	N/A	1 x HDMI Type A Female (Black)
Output	2 x HDMI Type A Female (Black)	1 x HDMI Type A Female (Black)
Control
RS-232	1 x Terminal Block, 3 Pole	1 x Terminal Block, 3 Pole
IR	2 x Mini Stereo Jack Female (Black)	2 x Mini Stereo Jack Female (Black)
Ethernet	1 x RJ-45 Female	1 x RJ-45 Female
Connectors
Power	1 x DC Jack	1 x DC Jack
Power Consumption	DC5.3V:9.12W:43BTU	DC5.3V:5.65W:26BTU
Environmental
Operating Temperature	0-50°C	0-50°C
Storage Temperature	-20 - 60°C	-20 - 60°C
Humidity	0 - 80% RH, Non-Condensing	0 - 80% RH, Non-Condensing
Physical Properties
Housing	Metal	Metal
Weight	0.46 kg ( 1.01 lb )	0.46 kg ( 1.01 lb )
Dimensions (L x W x H)	14.17 x 10.30 x 3.00 cm (5.58 x 4.06 x 1.18 in.)	14.17 x 10.30 x 3.00 cm (5.58 x 4.06 x 1.18 in.)
Carton Lot	5 pcs	5 pcs
