7 x 3 Seamless Presentation Matrix Switch with Scaler, Streaming, Audio Mixer, and HDBaseT

Seamless Multi-format AV Switching
Supports multi-format 7 Inputs:
•  2 combo inputs (HDMI/VGA, HDMI/DisplayPort)
•  3 HDMI inputs
2 HDMI and 1 HDBaseT outputs

• Superior video quality up to 1080p @ 60Hz (HDMI/DisplayPort)
• Ultra Seamless Switch™ – zero second switching that provides continuous video streams, real-time switching and stable signal transmissions
• Scaler – features a video scaling function to convert input resolutions to the optimum display resolutions
• Flexible aspect ratio conversion
• 1080p Streaming for Distance-free Sharing and Collaboration
• Go Live – meeting moderator can broadcast HD video streams to up to 5 remote locations
• Streaming In – remote locations can stream and share content to the meeting moderator at any distance via intuitive web GUI
• Streaming Queuing – shares the streamed-in content approved by the meeting moderator one at a time to help manage the meeting flow
• Audio Mixer Integration for Advanced Applications
• Audio Mixer – allows mixing of the microphone inputs to any external analog or digital audio output device
• Embed/De-embed Audio – HDMI/DisplayPort audio signals can be extracted to separate digital/analog audio signals; Mic/Line audio can be embedded to HDMI audio
• Supports multi-format digital/analog audio outputs, including coaxial, TOSLINK and RCA
• Advanced Conferencing Management Features for Collaboration
• Multi-view – displays and switches simultaneously in any variation of full-screen, dual-view, tri-view, quad-view or PIP modes, with up to six sources displayed simultaneously on one screen
• Moderator Mode – enables the meeting moderator control other displays via host display
• Chat Room – facilitates real-time and precise communication among remote participants
• Screen Capture – captures anything on your screen with a click
• Freeze – freezes the screen for discussion or to control the meeting flow
• Streamlined Operation
• View and control via ATEN Video Presentation Control App in a swift and agile way
• Multiple Control Options – flexible control via built-in Web UI, Front Panel, OSD, IR Remote Control, and RS-232, and Mobile App
• Auto switching – automatically detects and switches to a new source as soon as it is connected for time-saving and convenience
