2-Port VGA Splitter Wall Plate (Plastic) (250MHz)

2-Port VGA Splitter Wall Plate (Plastic) (250MHz)

Product Code : VS82

Brand Category : Video Splitters

Description

"
  • One video input to 2 video outputs.
  • Cascadable to 3 levels - provides up to 8 video signals.
  • Supports up to 250 MHz bandwidth.
  • Long distance transmission - up to 30 m (210'). *
  • High video resolution - up to 1920 x 1440.
  • DDC, DDC2, DDC2B Compatible (Port 1 only).
  • Compact design with convenient topside connection, lays flat on a desktop or mounts on the wall.
  • Supports VGA, XGA, SVGA, UXGA and multisync monitors.
  • OS Support: Windows 2000, Windows XP, Linux, Mac and Sun

    * Video content sent over very long distance using a VGA cable might result in slight degradation of the video signal and quality.
"

Add to Query Cart PDF Download

Technical Specification

Video Input
Interfaces1 x HDB-15 Male (Blue)
Max. Distance1.8 m
Impedance75 Ω
Video Output
Interfaces2 x HDB-15 Female (Blue)
Impedance75 Ω
Video
Max. Bandwidth250 MHz
Max. ResolutionUp to 1920 x 1440
Max. DistanceUp to 30 m
Connectors
Power1 x DC Jack
Power ConsumptionDC9V:1.02W:5BTU
Environmental
Operating Temperature0-50°C
Storage Temperature-20 - 60°C
Humidity0 - 80% RH, Non-Condensing
Physical Properties
HousingPlastic
Weight0.14 kg ( 0.31 lb )
Dimensions (L x W x H)8.76 x 11.46 x 3.33 cm
(3.45 x 4.51 x 1.31 in.)
Carton Lot20 pcs
