2-Port VGA Splitter Wall Plate (350MHz)

2-Port VGA Splitter Wall Plate (350MHz)

Product Code : VS132

Brand Category : Video Splitters

Description

  • One video input to two video outputs
  • Cascadable to three levels – provides up to 8 video signals
  • Supports up to 350 MHz bandwidth
  • Long Distance Transmission – up to 65 m (210 ft) *
  • Superior video quality – 1920 x 1440
  • DDC, DDC2, DDC2B Compatible (Port 1 only*)
  • Supports VGA, SVGA, XGA, UXGA, QXGA, WUXGA and multisync monitors
    Note: If you connect a DDC type monitor to Video Out 1, all other monitors must be able to support the highest video resolution that the DDC monitor can provide.

    * Video content sent over very long distance using a VGA cable might result in slight degradation of the video signal and quality.

Add to Query Cart PDF Download

Technical Specification

Video Input
Interfaces1 x HDB-15 Male (Blue)
Impedance75 Ω
Max. Distance1.8 m
Video Output
Interfaces2 x HDB-15 Female (Blue)
Impedance75 Ω
Video
Max. Bandwidth350 MHz
Max. ResolutionUp to 1920 x 1440
Max. DistanceUp to 65 m
Connectors
Power1 x DC Jack
Power ConsumptionDC5.3V:0.42W:2BTU
Environmental
Operating Temperature0-50°C
Storage Temperature-20 - 60°C
Humidity0 - 80% RH, Non-Condensing
Physical Properties
HousingMetal
Weight0.19 kg ( 0.42 lb )
Dimensions (L x W x H)10.36 x 7.90 x 2.82 cm
(4.08 x 3.11 x 1.11 in.)
Carton Lot20 pcs
