Product Code : VS92DP
Brand Category : Video Splitters
| LEDs | |
| Status | DisplayPort Output x 2 (Blue) Power Input x 1 (Blue) |
| Video Input | |
| Interfaces | 1 x DisplayPort Male (Black) |
| Max. Distance | 15cm |
| Video Output | |
| Interfaces | 2 x DisplayPort Female (Black) |
| Max. Distance | Max 3m at 3840x2160@60Hz (4:4:4) - Single output Max 3m at 3840x2160@30Hz (4:4:4) - Dual output (MST/SST mode) |
| Video | |
| Max. Data Rate | 21.6Gbps (5.4Gbps per lane) |
| Compliance | DisplayPort 1.2 / HDCP 1.3 |
| Max. Resolution | Up to 3840x2160@60Hz (4:4:4, 8 bits) |
| Power Consumption | 2WATT(MAX)BTU |
| Connectors | |
| USB Port | USB Type Micro B x 1 (Firmware upgrade & power source) |
| Environmental | |
| Operating Temperature | 0-40 °C |
| Storage Temperature | -20 - 60 °C |
| Humidity | 0 - 80% RH, Non-Condensing |
| Physical Properties | |
| Housing | Metal (aluminum) |
| Weight | 0.09 kg ( 0.2 lb ) |
| Dimensions (L x W x H) | 8.80 x 6.00 x 15.00 cm (3.46 x 2.36 x 5.91 in.) |
| Carton Lot | 10 pcs |
