10.1" Touch Panel

Product Code : VKT100

Brand Category : Control System

Description

  • 10.1” touch panel with a quad-core processor
  • Natively installed ATEN Control System app and designed for the integrated use with the ATEN Control System
  • Supports Power over Ethernet (PoE), which allows it to receive power and communication over a single Ethernet cable
  • Capacitive multi-touch screen
  • Flexible installation and available for the additional tabletop kit (ATEN VKTA101) and compatible for any standard VESA 75 x 75 mm mounts

Add to Query Cart PDF Download

Technical Specification

Panel Spec
Display Type10.1" TFT LCD
Touch ScreenCapacitive
Resolution1280x800
Aspect Ratio16:9
Color Depth8bit
Contrast Ratio800:1
BacklightLED
Viewing AngleVertical ± 85°, Horizontal ± 85°
Memory
RAM2GB
Storage Capacity8GB
Interfaces
Ethernet1 x RJ-45 Female, 10/100/1000Base-T
USB1 x USB Type A
Power
Power over Ethernet (PoE)802.3 af PoE/
802.3 at PoE+
Power ConsumptionDC48V:20WBTU
Environmental
Operating Temperature0 – 40°C
Storage Temperature–10 – 55°C
Humidity10 - 80% RH, Non-Condensing
Physical Properties
HousingABS + PC
Weight0.62 kg ( 1.37 lb )
Dimensions (L x W x H)25.22 x 17.78 x 2.45 cm
(9.93 x 7 x 0.96 in.)
